      Automatic Plywood Double Sizer (ZX - 4x8- SZ)

      Automatic Plywood Double Sizer (ZX - 4x8- SZ)

      Product Details:

      X

      Price And Quantity

      • INR/Unit
      • 1 Box

      Trade Information

      • 100 Box Per Month
      • 1 Months

      Product Description

      https://youtu.be/7LJZ7wiKM7k


      Specifications:

      Cutting Length

      1830~2500 mm

      Cutting width

      915~1250 mm

      Max. main saw size

      305 mm

      Scoring saw size dia.

      180 mm

      Feeding speed

      30-60 m/min

      Thickness Range

      2 ~ 60 mm

      RPM of Saw Blade

      6000 r/min

      Dust outlet holes

      4x108mm

      MOTOR

      POWER

      Main Saw Motors

      10 HP x 4 nos.

      Scoring Saw Motor

      2 HP x 4 nos.

      Automatic Stacker

      4 HP

      Feeding motor

      5 HP x 2 (Servo Motor)

      Production Capacity

      One minute can cut 2 Cycle

      Working Style

      Infraed & Ray Guidance

      Overall Dimensions

      6300 x 5000 x 1500mm

      All specifications, dimensions & design characteristic are subject to change without prior notice.
