FOUR ROWS MULTI BORING MACHINE (MZ7421B1 2V 2H)

MODEL

MZ7421B1

Max. panel width

2500mm

Min. panel width

90mm

Total No. of drilling blocks

6

No. of drilling blocks, Left

1

No. of drilling blocks, bottom

5

Total No. of drills

86

No. of drills, Left Blocks

21

No. of drills, Bottom Blocks

65

Spacing of drills

32mm

Max. panel thickness

70mm

Max. Drilling depth, vertical drills

70mm

Max. drilling depth, horizontal

40mm

Max. drilling distance, vertical

2405mm

Min. drilling distance, vertical

160mm

Motor of horizontal group

1.5kw

Motor of vertical group

6.7kw

Total power

8.2kw

In-put voltage & Frequency

460V/60HZ

Working height

900mm

Rotating speed of spindle

spindle: 2800rpm

Air pressure

6-8kg/cm2

Air consumption for a cycle

72L

Net weight

1640kg

Overall dimensions (L-W-H)

3460-2835-1460mm
