TWO HEAD WIDE BELT SANDING MACHINE (1300-R-P)

Get a Price/Quote

MOQ : 1 Box

TWO HEAD WIDE BELT SANDING MACHINE (1300-R-P) Specification

Type
Two Head Wide Belt Sanding Machine

Material
Steel, MS (Mild Steel)

Capacity
High Production (Depending on Workpiece and Feed Speed)

Computerized
No

Automatic Grade
Automatic

Power
37 kW

Voltage
380V/415V (3-Phase)

Filling Heads
2 Heads (Roller + Pad)

Air Pressure
0.6 MPa

Weight
Approx. 3200 kg

Dimension (L*W*H)
2200 x 2200 x 2100 mm

Color
Grey & White

Working Width
1300 mm

Sanding Motors
Main motor 30 kW + 22 kW

Feed Speed
6-30 m/min (Variable)

Lifting Motor
0.37 kW

Abrasive Belt Size
1330 x 2200 mm

Dust Extraction Port Diameter
150 mm

Working Thickness
2.5-110 mm

Control Panel
Digital/Push button

Application
Wood, Plywood, MDF, Veneer, and Panel boards

Vacuum Pressure Table
Optional

Noise Level
<85 dB(A)

Feeding Motor
2.2 kW

TWO HEAD WIDE BELT SANDING MACHINE (1300-R-P) Trade Information

Minimum Order Quantity
1 Box

Supply Ability
100 Boxes, , Per Month

Delivery Time
1 Months

TWO HEAD WIDE BELT SANDING MACHINE (1300-R-P) About

Discover the elite TWO HEAD WIDE BELT SANDING MACHINE (1300-R-P), a rare masterpiece crafted for unparalleled finishing in wood, MDF, plywood, veneer, and panel boards. Engineered for instant savings and high production, its robust steel frame supports a 1300 mm working width and dynamic feed speeds up to 30 m/min. Reserve your advantage with dual sanding heads (roller + pad), powerful motors, and optional vacuum pressure table for supreme dust control. This automatic, high-capacity sander is perfect for manufacturers and traders seeking elite results and reliability.

Tailored Performance for Multiple Media

The TWO HEAD WIDE BELT SANDING MACHINE (1300-R-P) excels in both specific and general applications, processing wood, MDF, plywood, veneer, and panel boards with precision. Operators should feed workpieces onto the conveyor, set the desired feed speed (630 m/min), and adjust thickness to achieve optimal finishing. Designed for industrial direction of use, its robust build handles high-frequency production runs, ensuring uniform surface quality across diverse material types.

Seamless Dispatch and Secure Packaging

Goods are transported promptly from the designated FOB ports in India, ensuring timely delivery to all destinations. Machines are dispatched in sturdy packaging to safeguard each unit during transportation. Payment is accepted via standard terms, including advance transfer and verified letters of credit. The equipment is covered by secure handling protocols and delivered with comprehensive documentation, giving customers confidence that their investment is safeguarded throughout the transit process.

FAQs of TWO HEAD WIDE BELT SANDING MACHINE (1300-R-P):

Q: How is the TWO HEAD WIDE BELT SANDING MACHINE (1300-R-P) operated in an industrial setting?

A: Operators load the material onto the conveyor, set the feed speed and working thickness, and select digital or push-button controls to adjust settings. The automatic grade design simplifies workflow for consistent, high-quality results.

Q: What types of materials can be processed with this sanding machine?

A: This sander is suitable for wood, plywood, MDF, veneer, and various panel boards. Its versatility makes it ideal for manufacturers in different sectors seeking efficient and precise sanding.

Q: Where do you ship the TWO HEAD WIDE BELT SANDING MACHINE (1300-R-P) from?

A: The machine is exported, supplied, and shipped from India, with FOB (Free On Board) ports arranged according to customer preferences. Secure transport ensures safe delivery worldwide.

Q: What benefits does the vacuum pressure table offer?

A: The optional vacuum pressure table enhances dust extraction and improves material stability during sanding, resulting in better surface quality and a cleaner working environment.

Q: How is the machine packaged and dispatched for transportation?

A: Each unit is securely packaged with reinforced materials to prevent damage during transit. Goods are dispatched promptly, accompanied by detailed documentation to guarantee safe and transparent transportation.
