Drive Motors

E - Servo

Controls

Digital Signal Processor

X-Y Movement

Rack & Pinion, Gear Drive, Taiwan

Z Movement

20 mm, Ball Screw Drive, Hiwin

Computer interface

USB 2.0

Command Code

G Code

Spindle

HSD 6kw, Air Cooling, 18000 RPM, Italy

Oil Lubrication System

Standard

Working Voltage

AC 380V / IIz,3

Software

Optional

Maximum Speed

35000 mm/min

Resolutions

0.025 mm

X-Y-Z Axis Working Area

1300 x 2500 x 180 mm

Maximum Cutting Speed

25000 mm/min

Collect Type & Size

ER 32 (12.7, 6, 3.175)

Machine Size

1750 x 2760 x 1500 mm

Packing Dimensions

1860 x 3160 x 1720 mm
