4 FEET PUTTY LINE

4 FEET PUTTY LINE About

4 FEET PUTTY LINE

  VACUUM FEEDER

Side Ways Type having size 2300(L) x 700(W) x 1500(H)

  VACUUM PUMP having 1.5kw Motor.

  SCISSOR LIFT Size 8x4 with 3Tonne capacity having roller of the top with 3HP motor & Hydraulic Power Pack.

  POWERED ROLLER CONVEYOR 3100x1525mm long with 0.7kw motor.

  PUTTY MACHINE 4 feet capable of applying putty from 550mm thick board with 7.5kw motor. Putty mixing motor 3 HP & Recycle motor 1.5kw

  POWERED ROLLER CONVEYOR 4400x1525mm long with 1.5kw motor.

  STACKER WITH SCISSOR LIFT 3 Tonne capacity with power pack & 3kw motor having size 4100x1900x2400mm

  PUTTY FEEDER 3000mm long for transferring the putty from the mixture to the machine having 3kw motor.

  PUTTY CONVEYOR 1700mm long for transferring the putty from the machine to mixture having 2.2kw motor.

  PUTTY MIXTURE having 4kw motor with agitator.

  COOLING ARRANGEMENT 6mt long clamps with 3kw motor also having 3 fans.

  Having capacity approx. 300pcs / 10 hrs.

  Weight 12 Tonne
