        Two Head Top And Bottom Wide Belt Sanding Machine

        Two Head Top And Bottom Wide Belt Sanding Machine

        Product Details:

        • Automatic Grade Automatic
        • Weight 16000kgs Kilograms (kg)
        • Color White
        • Click to View more
        X

        Price And Quantity

        • 1 Box
        • INR/Unit

        Product Specifications

        • Automatic
        • 16000kgs Kilograms (kg)
        • White

        Trade Information

        • 100 Box Per Month
        • 1 Months

        Product Description

        TWO HEAD TOP AND BOTTOM WIDE BELT SANDING MACHINE MODEL KID-1300-RP (CHINA MAKE)
        Complete with Electric Control Panel and required motors having following features.
        The two heads having contact roller and pad capable of calibrating and sanding.
        Dia. of 1st head roller  320.
        Variable speed unit. (Frequency Control Drive).
        Cleaning and Polishing roller.
        Microcomputer Controller (The machine adopts the advanced computer terminal that makes the operation easy and clear).
        HEAVY AND STRONG STRUCTURE FRAME.
        The frame structure of the machine is heavy-duty which is composed of advanced Q235 high-quality plate box-type frame welding. The inside of frame is specially treated to eliminate the expansion gap of metal temperature difference thus improving the stability of high-speed running of the equipment and achieve the functions of shock absorption, vibration absorption and noise elimination.
        SANDING BELT TENSIONING BEAM AND STRUCTURE
        Adopting the structure of double air cylinder to tension the sanding  belt, so as to balance the forces on every points of the belt and ensure the smooth rotary running, improving service life and sanding effect of the belt.
        SANDING ROLLER DRIVING PARTS
        Adopting high-quality couplet imported from Italy,
        improving the transmission strength and damping effect, changing the original transmission structure, and protecting the transmission shaft of sanding roller is not affected by radial force to ensure the service life.

        Specification:

        Working width

        1300mm

        Working thickness

        5-100mm

        Working length

        > 500mm

        Sanding belt linear speed

        26 mm/s

        Precision

        A 0.08 mm

        Feed speed

        8-40m/min

        Top & Bottom Head Motor

        75 / 55 kw x 2 nos.

        PLC

        Siemens

        Touch Screen

        Siemens

        Touch Screen

        Hanging Type

        All major Electricals

        Siemens

        Bearing

        FAG / SKF

        Work pressure

        0.55Mpa

        Air flow quantity

        42000m3/h

        Sanding Belt size

        3100x1350 mm

        Net weight

        16000kgs

        All specifications, dimensions & design characteristic are subject to change without prior notice.
