FOUR ROWS MULTI BORING MACHINE (MZ7421B 3V - 1H))

MODEL

MZ7421B

Max. panel width

2500mm

Min. panel width

90mm

Total No. of drilling blocks

7

No. of drilling blocks, Left

1

No. of drilling blocks, bottom

2 x 3=6

Total No. of drills

87

No. of drills, Left Blocks

21

No. of drills, Bottom Blocks

2 x 11 x 3=66

Spacing of drills

32mm

Max. panel thickness

70mm

Max. Drilling depth, vertical drills

70mm

Max. drilling depth, horizontal

40mm

Max. drilling distance, vertical

2405mm

Min. drilling distance, vertical

160mm

Motor of horizontal group

1.5kw

Motor of vertical group

1.3kw x 6=7.8kw

Total power

9.3kw

Working height

900mm

Rotating speed of spindle

2800rpm

Air pressure: 6-8kg/cm2

6-8kg/cm2

Air consumption for a cycle

58.5L

Net weight

1640kg

Overall dimensions (L x W x H)

3460 x 2835 x 1460mm
