      Auto Planner Wide Belt Sander Machine (1000-K-R-RP)

      Auto Planner Wide Belt Sander Machine (1000-K-R-RP)
      Auto Planner Wide Belt Sander Machine (1000-K-R-RP)
      Send Inquiry
      Product Code : 1000-K-R-RP
      Price And Quantity
      • Minimum Order Quantity
      • 1 Unit
      • Price Range
      • 20000.00 - 8000000.00 INR/Unit
      Product Description

      Auto Planner Wide Belt Sander Machine (1000-K-R-RP)

      • Working width : 40”
      • Thickness: 5”
      • Sanding belt size : 40” x 103”
      • 1st main motor : 20hp
      • Spiral planer (dia. 160mm) tool of the 1st wheel.
      • 2nd main motor: 20 hp.
      • Drum dia. 190mm, Hardness : hs85+/-5 Duro.
      • 3rd main motor: 15 hp.
      • Drum dia: 165mm, Hardness ; hs 65+/-5 Duro.
      • Feed motor: 3hp.
      • Table hoist motor : ½ Hp.
      • Cleaning Brush Motor ½ Hp.
      • With Variable Frequency Feed Drive(VFD)
      • Spiral cutting blade size 15x15x2.5mm



      Specifications:

      Work width

      1000 mm

      Min work length

      370 mm

      Work thickness

      8 ~ 125 mm

      Planner cutting motor

      20 HP

      Second main motor

      20 HP

      Third head motor

      15 HP

      Feeding motor

      3 HP

      Table hoist motor

      1/2 HP

      Cleaning Brush motor

      1/2  HP

      1st Cutting head speed

      36 m/s

      2nd Head abrasive belt speed

      23 m/s

      3rd Head abrasive belt speed

      18 m/s

      Feeding speed

      3 ~ 18 m/min

      Abrasive belt size

      2620x1020 mm

      Work pressure

      0.4 ~ 0.6 mpa

      Air volume

      7500 m3

      Net weight

      3500 Kgs.

      All specifications,dimensions & design characteristic are subject to change without prior notice.

      Trade Information
      • Supply Ability
      • 100 Unit Per Month
      • Delivery Time
      • 1 Months
