      STRAIGHT LINE RIP SAW (KI-YRS-18)

      STRAIGHT LINE RIP SAW (KI-YRS-18)
      STRAIGHT LINE RIP SAW (KI-YRS-18)
      Send Inquiry
      Product Code : KI-YRS-18
      Price And Quantity
      • Minimum Order Quantity
      • 1 Unit
      • Price Or Price Range
      • INR/Unit
      Product Description

      Straight line RIP saw model KI-YRS-18 (Taiwan make)

      Complete with following features

      • The rip saw is equipped with a powerful motor assuring extremely smooth cutting
      • The series of rip saw is ruggedly constructed for oustanding cutting stability
      • Variable feed speed allows for cutting all types of wood material
      • Track chain conveyor ensures high straight accuracy
      • An optional laser marking unit will upgrade cutting efficiency.
      • The sturdy frame and rigid construction of the machine enables it to be continuously operated for a long duration.

      Specifications :

      Minimum working length

      200mm (8")

      Maximum thickness

      120mm (4.72")

      Distance between saw and column

      610mm (24")

      Saw arbor motor

      15HP

      Saw arbor speed

      3500 rpm

      Saw blade diameter

      dia. 300-400mm (12"-16")

      Saw arbor diameter

      dia. 38.1mm (1.5")

      Feed motor

      2HP (3HP on request)

      Feed speed

      15-36M/min (25-60M/min on request)

      Number of holding rollers

      8

      Work table height

      810mm (32")

      Table area (W x L)

      1260x1900mm (50"x75")

      Overall dimension (W x L x H)

      1430x2260x1460mm (56"x89"x57")

      Shipping dimension (W x L x H)

      1600x2100x1700mm (63"x83"x67")

      Net weight

      1550kgs (3414lbs)

      Gross weight

      1800kgs (3965lbs)

      All specifications, dimensions & design characteristic are subject to change with out prior notice.

      Trade Information
      • Supply Ability
      • 100 Unit Per Month
      • Delivery Time
      • 1 Months
