MECHANICAL COPY LATHE TC 1200

MECHANICAL COPY LATHE TC 1200

Product Details:

  • Product Type Woodworking Machine
  • Machine Type Other
  • Power Electric
  • Speed 900 - 1500 - 2200 - 3000 RPM
  • Dimension (L*W*H) 2400 x 1540 x 650mm Millimeter (mm)
  • Weight 400 Kg Kilograms (kg)
  • Color White
  • Click to View more
X

MECHANICAL COPY LATHE TC 1200 Price And Quantity

  • 1 Unit
  • INR/Unit

MECHANICAL COPY LATHE TC 1200 Product Specifications

  • Other
  • Woodworking Machine
  • 2400 x 1540 x 650mm Millimeter (mm)
  • White
  • Electric
  • 900 - 1500 - 2200 - 3000 RPM
  • 400 Kg Kilograms (kg)

MECHANICAL COPY LATHE TC 1200 Trade Information

  • 100 Unit Per Month
  • 1 Months

Product Description



Specifications

MODEL

TC 1200

Max. distance between centres

1200 mm

Height of centres over bed

120mm

Max. copying diameter

150 (106)mm

Max. diameter permitted by traveling steady

90 (65)mm

Connection for driving and tailstock centre

CM 3

Saddle feed speed

0 5 mt/min

Saddle return speed

5 mt/min.

Spindle motor

2,9 kW (HP 4)

Spindle speed R.P.M.

900 - 1500 - 2200 - 3000

Motor power of hydraulic unit

0,75 kW (HP 1)

Installed power

3,75 kW

Operating pressure

25  30 bar

Overall dimensions: (LxWxH)

2400 x 1540 x 650mm

Net Weight

400 Kg

Sound pressure level at operator position

71 db (A)

All specifications, dimensions & design characteristic are subject to change without prior notice.
