Hydraulic Band Saw Double Side Equalizing Machine (EM-92H)
Product Details:
- Product Type Woodworking Machine
- Voltage 380V, 3Ph, 50Hz Volt (v)
- Power Electric
- Dimension(L*W*H) 80*140*150cm Centimeter (cm)
- Weight 430/455kg Kilograms (kg)
- Color White
- Supply Ability : 100 , , Unit Per Month
- Click to view more
Price And Quantity
- 80000.00 - 800000.00 INR/Unit
- 1 , , Unit
Product Specifications
- Woodworking Machine
- 80*140*150cm Centimeter (cm)
- 380V, 3Ph, 50Hz Volt (v)
- White
- Electric
- 430/455kg Kilograms (kg)
Trade Information
- 100 , , Unit Per Month
- 1 Months
Product Description
Hydraulic Band Saw Double Side Equalizing Machine (EM-92H)
EM-92His an ideal machine to equalize both sides of the stellite tipped or swaged band saw teeth. EM-92H simultaneously grinds two sides of the band saw teeth to provide flawless surface quality of the material cut. Hydraulic movement makes the tough cycles easier and control panel enables spark-out function upto 6 times.
Technical specifications:
MODEL | EM-92H |
Band saw blade width | 80-360 mm |
Band saw length | Min. 5.5m |
Tooth pushing stroke | 20-60mm |
Clearance angle in feeding and cutting direction | 0-7 |
Side dressing wheel outside diameter | 80mm |
Wheel bore diameter | 20mm |
Feeding rate | 40 teeth/min. |
Motor quantity | 3 |
Installed power | 1kW |
Operating voltage | 380V, 3Ph, 50Hz |
Net/gross weight | 430/455kg |
Dimensions | 80*140*150cm |
Hydraulic power unit | |
Hydraulic pump capacity | 9 lt/min. |
Working pressure | 20 bar. |
Container capacity | 20 lt. |
Oil type | Tellus 37 |
Number of valves in use | 2 units. |
All specifications, dimensions & design characteristic are subject to change without prior notice.
