Double End Tennoner (ECT-84A)

Double End Tennoner (ECT-84A)

Product Details:

  • Product Type Woodworking Machine
  • Machine Type Other
  • Power Electric
  • Automation Automatic
  • Motor 17hp
  • Speed 6-20M/min (variable) m/m
  • Color White,Blue
  • Click to View more
X

Double End Tennoner (ECT-84A) Price And Quantity

  • 1 Unit

Double End Tennoner (ECT-84A) Product Specifications

  • Electric
  • White,Blue
  • 17hp
  • Automatic
  • Other
  • Woodworking Machine
  • 6-20M/min (variable) m/m

Double End Tennoner (ECT-84A) Trade Information

  • 100 Unit Per Month
  • 1 Months

Product Description

Double End Tennoner (ECT-84A)
  • Central supporter.
  • Auto-positioning for movable side of machine via digital width controller to ensure accurate width setting.
  • Digital red-out devices for adjustment of top pressure beams and working units.
  • Rubber surfaced feed chaintrack.
  • Standard dogs (height = 12mm, dogs leading workpieces, distance between dogs= 400mm)
  • Safety covers for top and bottom pressure beams.
  • 205mm sawblade for scoring unit(2 units)
  • 255mm sawblade for main saw unit (2 unit)
  • Sawblade fange for scoring and main sawunits (4 units)
  • Tool box.
  • Operation manual

Specifications:

MODEL

ECT-84A

Working width range

210-2450mm

Max. working thickness calibration

60mm

Scoring saw system

2hp x 2 units at 3000rpm(50hz);
(saw blade)  205mm;
(spindle)  25.4mm, length 60mm;
tiltable to 90deg

Main saw system

5hp x 2 units at 3000rpm(50hz);
(saw blade) 255mm;
(spindle) 25.4mm, length 60mm;
tiltable to 90deg

Feed motor

2hp

Feed speed

6-20M/min (variable)

Motor for width adjustment

1hp

Total horsepower

17hp

All specifications,dimensions & design characteristic shown in the catalogues are subject to change without prior notice.
