Gang Saw For Cutting Round Log Diameter

Gang Saw For Cutting Round Log Diameter
Gang Saw For Cutting Round Log Diameter
Product Code : 74
Product Description

GANG SAW FOR CUTTING ROUND LOG,       DIAMETER 7”

Ø  With Laser Gun

Ø  With required motors:

Ø  Main Motor   (30 H.P X  2 No’s)

Ø  Feed Motor   2 H.P

Ø  Water Pump 0.25 HP - to spray the water on the saw blade for cooling.

Ø  Control Panel.

Capacity to cut round log upto 24" girth



GANG SAW FOR CUTTING ROUND LOG      DIAMETER f 12”

Ø  Control Panel.

Ø  Capacity to cut round log upto 34" girth.



Specifications:

Max. working diameter

280 mm

Min. working length

150 mm

Max. working length

3500 mm

Min working length

800 mm

Feeding power

1.5 kw x 2 (4.1 HP)

Up spindle power

30 Kw (41 HP)

Bottom spindle power

37 Kw ( 50.3 HP)

Total power

70 Kw (95.4 HP)

Feeding speed

0-8 m/min

Saw blade specification

405x4.0x60x40Tx6K

Overall dimension

4600x2100x1800

Weight

2750 kg

All specifications, dimensions & design characteristic are subject to change without prior notice.
