Dust Collector

Dust Collector
Dust Collector
Product Code : Dust Collector
Product Description

The offered Dust Collector is suitable for collecting various kinds of coarse dust, chips and other fine wooden aggregates form the machines and working environments. In order to manufacture this collector in line with international quality standards, our skilled team of professionals make use of top-notch quality components and avant-garde techniques. Further, provided collector is also stringently tested by our quality inspectors on set qualitative parameters to ensure its flawless operations. Clients can avail this Dust Collector from us in various designs, capacities and technical specifications at competitive prices.

Features:

  • Unmatched performance

  • Sturdy construction

  • Dimensional stability

  • Long service life

Technical Specfications:







Model KI-DC-200 KI-DC-250 KI-DC-600
Motor Power (kw) 1.5 3 5.5(7.5)
Air Delivery (m3/h) 2000 2500 6000
Air Speed (m/s) 20-25 35-40 40-45
Inlet Size (mm) 4 —3 4— 3 4 — 6
Fan Diameter (mm) 300 300 400
Collector Bag Dia.(pcs) 480 — 1100 — 1 480 — 900 — 2 640 — 100 — 4
Filter Bag Dia. (pcs) 480 — 1100 — 1 480 — 1100 — 2 640 — 1200 — 4
Overall Size (mm) 960—580—2280 1430 — 600 — 2280 1550 — 1550 — 2520
Packing Size (mm) 1000×580×580 1310 — 580 — 580 1300—660—660, 15201520—660, 1450—5700—660
Net Weight (kg) 62 68 202
Gross Weight(kg) 65 75 212

All specifications, dimensions & design characteristic are subject to change without prior notice.

Dust Collector Model DC-750

Technical Specifications:

Model KI-DC-750
Motor Power (kw) 7.5
Air Delivery (m3/h) 7500
Inlet Size Dia. (mm) 4 6
Collector Bag Dia.(pcs) 640 — 100 — 4
Filter Bag Dia. (pcs) 640 — 1200 — 4
Gross Weight(kg) 282

All specifications, dimensions & design characteristic are subject to change without prior notice.

Dust Collector Model DC-800

Technical Specifications:

Model KI-DC-800 KI-DC-1200
Motor Power 7.5 kw 11 Kw
Air Delivery 8000 m3/h 12000 m3/h
Air Speed 40-45 m/s 40- 45 m/s
Inlet Size 4 Dia x 4pcs 4 Dia x 6 pcs
Fan Diameter 600 mm 700 mm
Collector Bag 640 Dia x1000x3 pcs 640 Dia x 1000 x 4 pcs
Filter Bag 150Dia x1600x36 pcs 150 Dia x 1600 x 48 pcs
Overall Size 3320x1130x3150 mm 4300 x 1130 x 3150mm
Packing size 1410x220x460 mm 2360x1190x610 mm 1190x1080x880 mm 1630x1160x580mm 1160x1080x880 mm 1080x220x660 mm
Net weight 395 kg 560 kg

All specifications, dimensions & design characteristic are subject to change without prior notice.
