Home » Products » Woodworking Machines » PNEUMATIC CUT-OFF-SAW

PNEUMATIC CUT-OFF-SAW

PNEUMATIC CUT-OFF-SAW
PNEUMATIC CUT-OFF-SAW
Product Code : CUT-OFF-SAW
Product Description

PNEUMATIC CUT-OFF-SAW

  • PNEUMATIC CUT-OFF-SAW MODEL YFC-14
  • PNEUMATIC CUT-OFF-SAW MODEL YFC-18
  • PNEUMATIC CUT-OFF-SAW MODEL YFC24

OPTIONAL :

  • Infeed and Outfeed Roller Conveyor
  • Safety Guard
  • Safety Switch

MODEL

YFC-14

YFC-18

YFC-24

Cutting capacity (thickness x width)

1" x 10", 2" x 9", 3" x 8"

2" x 12", 3" x 11", 4" x 10"

2" x 21", 4" x 19", 6" x 15", 8" x 8"

Cycle speed

95

45 strokes/min

40 strokes/min

Cycle operation

Air

Air

Air / mechanical

Saw blade size (optional)

14"

18"

20" / 22" / 24"

Saw arbor diameter

1"

1"

1"

Saw blade speed

4100 RPM

3600 RPM

2400 RPM

Dust exhaust diameter

Ø4"

Ø4"

Ø4"

Motor

5 HP (7 1/2 HP opt.)

7 1/2 HP

7 1/2 HP (10 HP)

Table size

630 x 590 mm

660 x 700 mm

1150 x 660 mm

Net weight

240 kgs

350 kgs

480 kgs

Gross weight

290 kgs

410 kgs

560 kgs

Packing dimensions (L x W x H)

770 x 760 x 1300 mm

940 x 850 x 1350 mm

1360 x 900 x 1450 mm

We reserve the right to modify design without prior notice.
