AUTO PLANNER (SPIRAL CUTTERHEAD) (LSC-630MH)

AUTO PLANNER (SPIRAL CUTTERHEAD)  (LSC-630MH)
AUTO PLANNER (SPIRAL CUTTERHEAD) (LSC-630MH)
Send Inquiry
Product Code : LSC-630MH
Product Description

                   Specifications:

MODEL

LSC-630MH

Table Area

38”x25” (965x 635mm)

Cutterhead Diameter

3.86” (98mm)

Cutting Circle

4" (101mm)

Cutterhead Speed Spiral

5500 rpm

Spiral Raw Numbers

6

Knife Insert Size

15x15x2.5 mm

Feed rollers

3” (75mm) x 2

Table rollers

2-1/2” (65mm)

Range of feed speed  (3 Speeds)

6, 9, 12 m/min

Maximum Depth of Cut

8mm

Stock thickness range

¼” - 8” (6 – 203mm)

Max. width of stock

24” (609mm)

Cutterhead motor

10HP / 3PH

Feed drive motor

1HP

Net weight

900 kgs

Gross weight

1000 kgs

Packing dimensions

48”x45”x54”

All specifications,dimensions are subject to change without prior notice.
