VENEER EDGE GRINDER (DEG 130)

VENEER EDGE GRINDER (DEG 130)
VENEER EDGE GRINDER (DEG 130)
Send Inquiry
Product Code : DEG 130
Product Description

Veneer Edge Grinder- Double Side Model- DEG 130

  • Complete with following features
  • With required motors and electrical panel
  • Strong structure having chain transmission and adjustable chain conveyors which runs throughout, holds the veneer from top and bottom while grinding/scarfing takes place thus ensuring the stable grinding/beveling.
  • Grinding station/Heads can tilt/incline to grinding/scarf/beveling of edges of the core veneer.
  • Can scarf/grind length of the core veneer from 700-1300mm
  • 2 Nos. Grinding heads on the either side of the machine i.e. total 4 Grinding heads.
  • The grinding head can be adjusted according to the thickness of core veneer.

Technical Specifications:

Grinding Thickness

0.8 ~ 5.0 mm

Grinding Width

5 ~ 30 mm

Working Length

700-1300 mm

Working Width

100-1300 mm

Variable Speed Motor

4Kw Taiwan make

Abrasive Belt Motor

3Kw x 4 Sets

Moving Beam Motor

0.37 Kw

Total Power

16.37 Kw

Dimension

2490 x 2250 x 1730mm

Total Weight

2000 Kg.

All specifications, dimensions & design characteristic are subject to change with out prior notice.
