THREE HEAD WIDE BELT SANDING MACHINE

Get a Price/Quote

Product Details:

Type Wide Belt Sanding Machine
Material Heavy Duty Steel Frame
Capacity Up to 1300 mm working width
Computerized No
Automatic Grade Automatic
Power 32 kW (Total Installed Power)
Voltage 380 V, 3 Phase, 50 Hz
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

THREE HEAD WIDE BELT SANDING MACHINE Price And Quantity

Minimum Order Quantity 1 Box

THREE HEAD WIDE BELT SANDING MACHINE Product Specifications

Automatic Grade Automatic
Color White & Blue
Capacity Up to 1300 mm working width
Power 32 kW (Total Installed Power)
Type Wide Belt Sanding Machine
Material Heavy Duty Steel Frame
Air Pressure 0.6 MPa
Voltage 380 V, 3 Phase, 50 Hz
Dimension (L*W*H) 2200 x 2200 x 2100 mm
Computerized No
Filling Heads 3 Sanding Heads
Weight Approx. 3500 kg

THREE HEAD WIDE BELT SANDING MACHINE Trade Information

Supply Ability 100 Box Per Month
Delivery Time 1 Months

Product Description

Specifications:

MODEL	KI-1300-RP-RP-B
Width of Panel	40-1300mm
Thickness of Sanded Panel	3160mm
Speed of Abrasive Belt on 1^st Unit	18 m/s
Speed of Abrasive Belt on 2^nd Unit	12 m/s
Speed of Conveyor Belt /Feed Speed	735 m/min
Size of Abrasive Belt	2620x1320 mm
Motor Required Brushing Unit	1^st Head 25 HP
	2^nd Head 25 HP
	3rd Head 7.5 H.P
Feed Motor	5 HP
Hoist Motor	0.5 HP
Vacuum fan motor	7.5 HP
Working Pressure	0.55 Mpa
Consumption of Compressed Air	1.56m3/ h
Volume of sucked air	7896m3/h
Average Speed of Sucked Air	2530 m/s
Overall Dimensions (LxWxH)	2600x3100x2750 mm
Weight	4300 Kgs.

Allspecifications are subject to change without prior notice

Efficient Multi-Head Sanding Performance

Utilizing three independent sanding heads, this machine ensures optimal material removal in a single pass, significantly improving production speed and surface uniformity. The heavy-duty construction supports intensive usage for demanding industrial environments, making each sanding operation smooth and reliable.

Enhanced Flexibility and User Control

The machine provides adjustable feed speeds ranging from 6 to 30 m/min, allowing operators to tailor sanding intensity to different wood species and panel thicknesses. Digital thickness display enables precise control over material dimensions, promoting consistency from batch to batch.

Robust Dust Extraction System

With three 150 mm dust extraction ports, the wide belt sanding machine maintains a clean working environment by efficiently collecting debris. This system reduces maintenance downtime and creates safer working conditions within busy manufacturing settings.

FAQs of THREE HEAD WIDE BELT SANDING MACHINE:

Q: How does the Three Head Wide Belt Sanding Machine improve sanding efficiency?

A: The three sanding heads operate simultaneously, enabling multiple sanding stages to be completed in one pass. This design increases overall productivity and ensures a uniform finish while reducing manual intervention.

Q: What types of materials can be processed with this machine?

A: This wide belt sanding machine is suitable for sanding wood, plywood, MDF panels, and particle board. Its adjustable settings accommodate various material thicknesses and densities commonly found in woodworking industries.

Q: When should I adjust the feed speed during operation?

A: Feed speed adjustment is beneficial when working with different materials or seeking specific finish qualities. Softer woods or thin panels may require slower speeds for finer results, while harder materials and thicker boards can be processed faster.

Q: Where is the machine commonly installed and used?

A: It is typically installed in woodworking factories, panel processing plants, and large-scale furniture manufacturing units across India, serving exporters, importers, manufacturers, suppliers, and traders who demand precise surface preparation.

Q: What is the process for changing the sanding belts?

A: The machine is engineered for straightforward belt changes. Once powered down, the sandbelt lifting motor (0.55 kW) facilitates easy access to each belt, allowing operators to safely remove and replace them as needed.

Q: How does the dust extraction benefit the operation?

A: The integrated dust extraction ports effectively capture sanding debris, maintaining a cleaner workspace. This feature reduces cleaning time, improves operator health, and preserves machine integrity over extended periods of operation.
