ROUND ROD MILLING MACHINE

ROUND ROD MILLING MACHINE
ROUND ROD MILLING MACHINE
Product Code : ROUND ROD MACHINE
Product Description

The offered Round Rod Milling Machine is designed and manufactured by our seasoned professionals using supreme quality components that are sourced from the authentic vendors of the market. This milling machine is ideal to produce round wooden rods from square shaped woods. Widely cherished for its unmatched performance and longer operational life, this Round Rod Milling Machine is made for clients in various designs and technical specifications at marginal prices.

Features:

  • Reliable operation

  • Simplified handling

  • Longer service life

  • Lower power consumption

Our range also includes:

  • Round Rod Milling Machine Model KI-CF-60

  • Multiple Round Rod Milling Machine Model KI-CF-60S

Round Rod Milling Machine Model KI-CF-60:

Technical Specifications:

Range of Working Diameter

6 to  60 mm

Range of Working Length

300 mm ~ unlimited

Drive motor

5 HP

Feed motor

2 HP

Cutterhead speed

3400 rpm

Range of Feed Speed

10/12/14/16 m/min(4 speeds)

Chip Chute Diameter

100 mm ( 4”)

Machine Size (LxWxH)

800x690x910mm

Machine Size (LxWxH)

890x730x1150mm

Net Weight

320 Kgs.

Gross Weight

370 Kgs.

All specifications, dimensions & design characteristic shown in the catalogue are subject to change without prior notice.

Multiple Round Rod Milling Machine Model KI-CF-60S:

Technical Specifications:

MODEL

KI-CF-60S

Range of Working Diameter

10 to  60 mm

Range of Working Length

400 mm ~ unlimited

Drive motor

71/2 HP / 5 HP

Feed motor

2 HP

Cutterhead speed

6000 rpm

Range of Feed Speed

14/16/18/20 m/min (4 speeds)

Chip Chute Diameter

100 mm (4”)

Machine Size (LxWxH)

1360x690x910mm

Machine Size (LxWxH)

1470x715x1150mm

Net Weight

560 Kgs.

Gross Weight

650 Kgs.

All specifications, dimensions & design characteristic shown in the catalogues are subject to change without prior notice.
