Home » Products » Plywood Making Machines » PEELING KNIFE GRINDER MACHINE

PEELING KNIFE GRINDER MACHINE

PEELING KNIFE GRINDER MACHINE
PEELING KNIFE GRINDER MACHINE
Product Code : 1400, 2700mm
Product Description

By offering Peeling Knife Grinder Machine at market leading prices, we have gained immense recognition as the foremost manufacturer, exporter and supplier in this domain. Provided machine is well suited for the grinding of various kinds of grinding blades to ensure the precise and finished cutting. Provided machine is manufactured by our dexterous professionals using optimal quality components and progressive techniques in compliance with set international standards. To meet the specific needs of clients, we offer this Peeling Knife Grinder Machine in several design and technical specifications at marginal prices.

Features:

  • Optimum performance

  • Maintenance free

  • Lower power consumption

  • Longer service life

PEELING KNIFE GRINDER MACHINE 1400 & 2700mm

Specifications:

Length of Cast Iron table

1450 mm.

Grinding width

150 mm.

Clearance

125 mm.

Power required

Motor for Grinding Heard

5 H.P.

Movement of Grinding Head Carriage

½ H.P.

All specifications, dimensions & design characteristic are subject to change without prior notice.
Peeling Knife Grinder Machine 2700mm


Specifications:

Length of Cast Iron table

2750 mm.

Grinding width

200 mm.

Clearance

150mm.

POWER REQUIRED

Motor for Grinding Heard

7.5 H.P.

Movement of Grinding Head Carriage

1 H.P.

All specifications, dimensions & design characteristic are subject to change without prior notice.
Peeling Knife Grinder Machine 2700mm with Magnetic Chuck


Specifications :

Max. Cutting Length

3000

Electrical Magnetic Table (mm)

180

Grinding Head Speed (m/s)

15

Sliding Head Speed (m/s)

04/25/09

Grind Wheel Size (mm)

200×100×32

Motor Power (kw)

4

Worktable Tilt Angle

±900

Grind Head Tilt Angle

±300

Net Weight (Kg)

2600

All specifications, dimensions & design characteristic are subject to change without prior notice.
Peeling Knife Grinder Machine 4000mm with Magnetic Chuck


Specifications :

Max. Grinding Length

4200

Electrical Magnetic Table (mm)

200

Grinding Head Speed (m/s)

19

Speed / To & Fro movement of Grinding Head

7-16 m/min.

Grind Wheel Size (mm)

255×195×135

Motor Power (kw)

7.5

Worktable Tilt Angle

0 - 900

Grind Head Tilt Angle

0 - 70

Hydraulic Motor

2.2 kw

Cooling Motor

0.15kw

All specifications, dimensions & design characteristic are subject to change without prior notice.
