Hydraulic Scissor Lift (12D/L)

Get a Price/Quote

Product Details:

Type Hydraulic Scissor Lift (12D/L)
Material Mild Steel
Computerized No
Power Hydraulic
Weight 900 kg (approx.)
Dimension (L*W*H) 3000 x 1200 x 1000 mm
Color Yellow
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Hydraulic Scissor Lift (12D/L) Price And Quantity

Minimum Order Quantity 1 Box

Hydraulic Scissor Lift (12D/L) Product Specifications

Weight 900 kg (approx.)
Material Mild Steel
Type Hydraulic Scissor Lift (12D/L)
Dimension (L*W*H) 3000 x 1200 x 1000 mm
Color Yellow
Computerized No
Power Hydraulic

Hydraulic Scissor Lift (12D/L) Trade Information

Supply Ability 100 Box Per Month
Delivery Time 1 Months

Product Description

HYDRAULIC SCISSOR LIFT (12D/L)

(Feeding the plywood into the platens from Bottom To Top with opening of 2800 mm.) For 12 Delight Press, having 3.5 tonne capacity. M.S.Heavy Duty Fabricated Body Structure. Complete with 1 No. cylinder, Power Pack and Electric Motor.

Specification:

Loading Side Structure	2800 x 1350x710mm
Unloading Side Structure	2800 x 1350x510mm
Hydraulic Cylinder Ram Dia	110mm
Power	3 HP
Total RAM Length (Loading Side)	2800mm
Hydraulic Cylinder Stroke (Loading Side)	2550 mm
Hydraulic Cylinder Stroke (Unloading Side)	1600 mm
Weight Lifting Capacity	3.5 Tonne
Weight	900 Kgs.

All specifications, dimensions & design are subject to change without prior notice

Adjustable Platform for Versatile Applications

The Hydraulic Scissor Lift (12D/L) comes with a customizable platform size, catering to various operational requirements in warehouses, factories, and loading docks. This flexibility enables precise adaptation to different material types and sizes, enhancing the efficiency of your material handling processes.

Comprehensive Safety and User Controls

With safety features including manual emergency lowering, safety stop, and an overload protection valve, the lift prioritizes operator and equipment security. Operation is straightforward via push button or pendant controls, ensuring reliable and safe performance every time.

FAQs of Hydraulic Scissor Lift (12D/L):

Q: How is the Hydraulic Scissor Lift (12D/L) installed at a worksite?

A: The lift is fixed-installed on-site, meaning it is securely anchored in place at your warehouse or material handling location to ensure stability during operation.

Q: What are the primary benefits of using this hydraulic scissor lift in warehouse operations?

A: It streamlines material handling tasks, improves safety, minimizes manual labor, and accommodates heavy or large loads efficiently, enhancing overall productivity.

Q: When should the manual emergency lowering feature be used?

A: This feature is employed in the event of a power failure or system fault, allowing operators to safely lower the platform and ensure the safety of personnel and cargo.

Q: Where can this hydraulic scissor lift be used effectively?

A: It is suitable for both indoor and outdoor environments, including warehouses, manufacturing units, and loading docks where stable and reliable vertical lifting is required.

Q: How does the overload protection valve contribute to operational safety?

A: The overload protection valve prevents the lift from operating if the load exceeds its rated capacity, protecting both the machinery and operators from potential harm.

Q: What is the recommended method for operating this lift?

A: The lift can be operated using either the integrated push button controls or a pendant control, providing flexibility and ease of use for different operator preferences.
