HEAVY DUTY AUTOMATIC COPY SHAPER (KI-KL-80AS)

HEAVY DUTY AUTOMATIC COPY SHAPER (KI-KL-80AS)
HEAVY DUTY AUTOMATIC COPY SHAPER (KI-KL-80AS)
Send Inquiry
Product Code : KI-KL-80AS
Product Description

Model

KI-KL-80AS

Maximum Cutting Circle

80”

Minimum Cutting Circle

20”

Maximum Rectangle (2.1)

71”x35”

Table Diameter

f64”

Cutter Spindle Diameter

f30 mm

Follower Roller Diameter

f100 mm

Table Speeds

0.4~4.0RPM

(DC variable)

Cutter Spindle Speed

9,000RPM

Table Drive Motor

2 HP (DC)

Cutter Head Drive Motor

10HPx2

Sanding Motor

5HPx1HHP

Size of Sanding Belt

2,820 mm

Working Air Pressure Required

70PSI(5.0kg/cm2)

Net Weight

4,200kgs

Gross Weight

4,500kgs

All specifications, dimensions are subject to change withoutprior notice.
