GANG RIP SAW (KI-305H)

GANG RIP SAW (KI-305H)
GANG RIP SAW (KI-305H)
Send Inquiry
Product Code : KI-305H
Product Description

Gang RIP SAW Model KI-305 H (Taiwan Make)

  • With capacity to take plank of maximum 125mm thick x 305mm wide.
  • With electric control panel
  • Machine is with 30 HP motor
  • Variable speed drive for the control of the feed.
  • To cut dry and semi dry timber
  • Frame of the machine in Cast Iron (C.I. Casting)
  • Surface of the table is hard chromed
  • Top Feed Roller-6 set (3 segment rollers= 1 set)
  • Bottom table roller-4 pcs

Technical Specifications

MODEL

KI-305H

Maximum working width & thickness

305 x 125 mm

Maximum saw dia.

405mm

Saw spindle dia. / key groove

f 70mm+20 x 6 Twin diagonal square key

Variable feeding speed

6-24 m/min.

Saw spindle speed

3600 rpm

Minimum working length

230 mm

Top Feed Rollers
(3 Segment Rollers = 1 Set)

6 Sets

Bottom Table Roller

4 pcs

Saw spindle motor

30 / 40 / 50 HP

Feeding motor

2 HP

Feed rollers elevation motor

HP

Saw spindle elevation motor

HP

Net Weight

1800 kgs.

Gross Weight

1900 Kgs

Machine dimensions (LxWxH)

2200X1100x1550mm

Packing dimensions (LxWxH)

2300x1150x1600mm


All specifications,dimensions & design characteristics are subject to change without prior notice.
